Storage Containers

Schoeller Arca System 9000 Containers

System 9000 drawer containers are particularly suitable for use in small parts automated Vertical Storage and retrieval systems and are used extensively in Kardex, Linpic and Megamat Vertical Carousels and Kardex Vertical Shuttle units.

There are three sizes available to suit specific Carousel or Shuttle Systems in depths of 300mm, 400mm and 500mm.


The containers are manufactured in heights of 82mm and in widths of either 94mm or 188mm. The System 9000 Drawer containers are available in blue.

Each container has the ability to be sub divided across the width to then maximise the number of locations and consequently number of parts stored within each container.

Additionally we can offer Schoeller Arca Storage Trays which are also suitable for use in small parts automated Vertical Storage and retrieval systems and Vertical Storage Shuttles.

These containers are available in either Blue or Red which then allows for the easy colour coding of parts and systems within the carousel or shuttle and they are available in lengths of 500mm or 600mm, widths of 115mm and 230mm and with heights of either 62mm or 100mm to suit the different Carousel or Shuttle shelf configurations.
Full width labels are available for the containers to allow the easy visual location of component parts.

The Arca System 9000 Containers are manufactured from Polypropylene which has a temperature tolerance of -20C to 80C and can withstand the effects of most oils, acids and solvents.

Please Contact us for a free no obligation Quotation if you have a Kardex, Linpic or Megamat Vertical Storage Carousel that you are looking to purchase high density storage containers for.
